Cisco
NEW Cisco WS-C3850-48XS-E 48x 10GB SFP+ 4x 40GB QSFP+ F-B Airflow Switch
- MPN:
- WS-C3850-48XS-E
- Condition:
- New
- Shipping:
- Calculated at Checkout
Description
NEW Cisco WS-C3850-48XS-E 48x 10GB SFP+ 4x 40GB QSFP+ F-B Airflow Switch
WS-C3850-48XS-E-Ref Overview
Standalone Cisco Catalyst 3850 Switch that supports SFP+ transceivers, 48 ports that support up to 10G, and 4 QSFP ports that support up to 40G, and 750 WAC front-to-back power supply. 1 RU.
Integrated wireless controller capability with:
◦ Up to 40G of wireless capacity per switch (48-port RJ45 models)
◦ Support for up to 100 access points and 2000 wireless clients on each switching entity (switch or stack)
● 24 and 48 10/100/1000Mbps data PoE+ and Cisco UPOE models with Energy-Efficient Ethernet (EEE)
● 24 and 48 100Mbps/1/2.5/5/10 Gbps Cisco UPOE models with Energy-Efficient Ethernet (EEE)
● 12- and 24-port 1 Gigabit Ethernet SFP-based models
● 12- and 24-port 1/10 Gigabit Ethernet SFP+-based models
● 48-port 1/10 Gigabit Ethernet SFP+ model with 4 fixed 40 Gigabit Ethernet QSFP+ uplinks
● Cisco StackWise-480 technology provides scalability and resiliency with 480 Gbps of stack throughput[1
● Cisco StackPower® technology provides power stacking among stack members for power redundancy1
● Five optional uplink modules[ with 4 x Gigabit Ethernet, 2 x 10 Gigabit Ethernet, 4 x 10 Gigabit Ethernet 8 x 10 Gigabit Ethernet4, or 2 x 40 Gigabit Ethernet QSFP+ ports
● Dual redundant, modular power supplies and three modular fans providing redundancy
● Full IEEE 802.3at (PoE+) with 30W power on all copper ports in 1 Rack Unit (RU) form factor
● Cisco UPOE with 60W power per port in 1 Rack Unit (RU) form factor
● IEEE 802.3bz (2.5/5 G/s BASE-T) to go beyond 1 Gb/s with existing Cat5e and Cat6
● IEEE 802.1ba AV Bridging (AVB) built-in to provide better AV experience for including improved time synchronization and QoS
WS-C3850-48XS-E-Ref Specification
- Type:Virtual interfaces (VLANs)
- Value:4000
- Width:17.5 in
- Depth:20.1 in
- Height:1.8 in
- Weight:16.42 lbs
- Min Operating Temperature:23 °F
- Max Operating Temperature:113 °F
- Humidity Range Operating:10 - 95% (non-condensing)
- Min Storage Temperature:-40 °F
- Max Storage Temperature:158 °F
- Installed Size:8 GB
- Compatibility:PC
- Manufacturer:Cisco Systems
- Packaged Quantity:1
- Product Line:Cisco Catalyst
- Model:3850-48XS-E
- Brand:Cisco
- Qty:48
- Type:Management (mini-USB)
- Connector Type:Type B
- Comments:Management
- Compliant Standards:AS/NZS 3548 Class A, AS/NZS CISPR 22, BSMI Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CNS 13438, EN 300386, EN 55022 Class A, EN 60950-1, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15, FCC Part 15 A, ICES-003 Class A, IEC 60950-1, IEC 60950-1 Second Edition, KCC, KN22 Class A, KN24, NOM, RoHS 5/6, UL 60950-1, UL 60950-1 Second Edition, VCCI Class A
- Authentication Method:Kerberos, RADIUS, Secure Shell (SSH), TACACS+
- MTBF:286,900 hours
- Height (Rack Units):1
- Color Category:Gray
- Type:Switch
- Connectivity Technology:Wired/Wireless
- Remote Management Protocol:CLI, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet, TFTP
- Compliant Standards:IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.3z
- Status Indicators:Active, Port duplex mode, Port transmission speed, Power, Status, System
- Ports Qty:48
- Features:802.1x authentication, Access Control List (ACL) support, ARP inspection, ARP support, Bridge protocol data unit (BPDU), Cisco StackPower technology, Cisco StackWise-480 technology, Control plane protection (CoPP), DHCP snooping, DHCP support, Dynamic Trunking Protocol (DTP) support, Energy Efficient Ethernet, Flexible NetFlow (FNF), Front to back airflow, Link Aggregation Control Protocol (LACP), Multiple Spanning Tree Protocol (MSTP) support, PIM snooping, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), Radio resource management (RRM), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), SSH support, Syslog support, Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), Virtual Route Forwarding-Lite (VRF-Lite), Virtual Routing and Forwarding (VRF), VLAN Trunking Protocol (VTP), Weighted Tail Drop (WTD)
- Routing Protocol:BGP-4, EIGRP, EIGRP for IPv6, IGMP, IGMPv2, IGMPv3, IS-IS, MLD, MLDv2, OSPF, OSPFv3, PIM-DM, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng
- MAC Address Table Size:32000 entries
- Stackable:Stackable
- Subcategory:Network hubs and switches
- Advanced Switching:Layer 3
- Manageable:Yes
- Form Factor:Desktop, Rack-mountable
- Jumbo Frame Support:9198 bytes
- Subtype:10 Gigabit Ethernet
- Type:Switching capacity
- Value:1280 Gbps
- Qty:48
- Type:1 Gigabit / 10 Gigabit SFP+
- Qty:4
- Type:QSFP+
- Frequency Required:50 - 60 Hz
- Power Provided:750 Watt
- Installed Qty:1
- Max Supported Qty:2
- Nominal Voltage:AC 120/230 V
- Power Redundancy:Optional
- Power Redundancy Scheme:1+1 (with optional power supply)
- Type:Internal power supply
- Installed Size:8 GB
- Support Details Type:Technical support
- Support Details Service Included:Consulting
- Support Details Full Contract Period:90 days
- Type:Limited lifetime warranty
- Response Time:Next business day
- Type:Cisco IOS IP Services
