Overview
The Cisco Catalyst CW9176I-CFG is a premier Wi-Fi 7 (802.11be) ultra-high-performance access point designed for high-density environments. It utilizes a tri-band architecture across 2.4 GHz, 5 GHz, and 6 GHz frequencies to deliver massive throughput and reduced latency for bandwidth-intensive applications. With integrated IoT support via Bluetooth Low Energy (BLE) and Thread, it serves as a versatile hub for modern enterprise connectivity. The Cisco CW9176I-CFG provides reliable, future-proof performance for Internet of Things devices and high-speed client access, ensuring seamless connectivity in diverse wireless environments. Cisco CW9176I-CFG: Catalyst CW9176I Indoor Wi-Fi 7 Access Point, configurable for various management modes.
Specifications
- Interface Ports: 1x 100M/1000M/2.5G/5G/10G BASE-T (mGig) Ethernet RJ-45, 1x USB 2.0 Type-A (4.5W power budget).
- Uplink options: The single RJ-45 port supports multi-gigabit speeds up to 10G and serves as both the data and Power over Ethernet (PoE) uplink interface.
- Management Ports: 1x RJ-45 Management Console Port.
- Antenna Ports: No external antenna ports - integrated internal antennas only.
- Antenna Options: Integrated omnidirectional antennas: 4 dBi at 2.4 GHz, 5 dBi at 5 GHz, 6 dBi at 6 GHz.
- Power Options: Powered via 802.3bt (UPOE/UPOE+) or 802.3at (PoE+). 802.3bt is required for full functionality across all radios. DC power input (54V) is also supported.
- Frequency: 2.4 GHz, 5 GHz, 6 GHz (Tri-band).
- Data Link Protocol: IEEE 802.11a/b/g/n/ac/ax/be (Wi-Fi 7).
- Licence: Configurable - DNA or Meraki licensing can be applied depending on the management platform chosen.
- Maximum Data Rate: 23.3 Gbps (Aggregate, Tri-band theoretical PHY rate).
- Regulatory domain: Global regulatory domains supported (configured via -A, -E, -B, etc., suffixes).
- Mounts: Ceiling and Wall Mount. Compatible with standard Cisco brackets: AIR-AP-BRACKET-1 (low profile) and AIR-AP-BRACKET-2 (universal).
- Model Number: CW9176I-CFG.
- Condition: New
Datasheet Cisco CW9176I-CFG Wireless 9176 Series Access Points
