Overview

The Juniper QFX10000-RE is the central Routing Engine (RE) module designed for the QFX10000 line of modular switches, specifically the QFX10008 and QFX10016 chassis. It serves as the control plane for the entire system, managing the Junos OS and coordinating all routing, switching, and management functions.

Specifications

• Management Ports: 1x 10/100/1000 Mbps RJ45 Management Ethernet port, 1x RJ45 Serial Console port, and 1x USB port for external storage and firmware loads.
• Time Source Connectivity: Dedicated ports (PTP/External Clock) provide connectivity to external time sources for synchronization.
• Management CPU: Quad-core Intel Ivy Bridge (x86) processor.
• System RAM: Varies by revision, typically starting at 16 GB to 32 GB.
• Storage: Onboard Solid-State Drive (SSD) for Junos OS, configuration files, and log files.
• Operating System: Junos OS, supporting modular software architecture with independent process modules.
• System Throughput Support: Designed to manage chassis with aggregate throughput up to 96 Tbps.
• High Availability: Supports Graceful Routing Engine Switchover (GRES), Nonstop Active Routing (NSR), and Nonstop Bridging (NSB) when paired with a redundant module in a 1+1 hot-standby configuration.
• Redundancy: Each modular QFX10000 chassis includes a secondary slot to accommodate a redundant RE module.
• Form Factor: Modular plug-in card for the control plane slots of modular QFX10000 chassis.
• Scalability: Supports up to 1 million MAC addresses and 2 million host routes.
• Compatible Chassis: Juniper QFX10008 (8-slot) and QFX10016 (16-slot).
• Model Number: QFX10000-RE.
• Condition: Refurbished
