HPE Aruba J9778A 2530-48-PoE+ 48x FE PoE+ RJ-45 2x 1GB RJ-45 2x 1GB SFP Switch

Quick spec of J9778A-Ref

• Product Code : J9778A
• Type : Aruba 2530-48-PoE+ Switch
• Ports : · 48 × RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+);Media Type: Auto-MDIX; Duplex: half or full· 2 × autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only· 2 × fixed Gigabit Ethernet SFP ports· 1 dual-personality (RJ-45 or USB micro-B) serial console port.
• Switching capacity : 17.6 Gb/s
• PoE power : 382 W
• Minimum dimensions (W x D x H) : 44.2 x 32.26 x 4.45 cm (17.4 x 12.7 x 1.75 in) (1U height)
• Weight : 4.58 kg (10.1 lb)

J9778A-Ref Specification

• Model:Aruba J9778A
• Brand:Aruba
• Number of Ports:48
• Flash Memory Installed:DDR3 SDRAM
• RAM Installed:256 megabyte
• Jumbo Frame Support:9220 bytes
• MAC Address Table Size:16000 entries
• Manageable:Yes
• Power Over Ethernet (PoE):PoE+
• Product Type:Switch
• Switching Type:Fast Ethernet
• Frequency:50/60 hertz
• Operating Humidity:15 - 95% (non-condensing)
• Device Type:Internal power supply
• Switching capacity:17.6 Gbps
• Throughput:13 Mpps
• Dimensions (W x D x H):17.4 x 12.7 x 1.8 in
• Limited Warranty:Limited lifetime warranty
