Dell PowerEdge R660xs 1U rackmount server featuring an Intel Xeon Gold 6526Y processor, 64GB of DDR5 memory, four Dell enterprise mixed-use SSDs, a PERC H755 RAID controller, iDRAC9 Enterprise, redundant power supplies, sliding rails, and factory Windows Server 2025 Standard licensing.
This is a current-generation enterprise server suitable for virtualization, databases, line-of-business applications, infrastructure services, storage-intensive workloads, lab environments, or deployment in a data center.
System Specifications
Server
-
Dell PowerEdge R660xs
-
1U rackmount chassis
-
8-bay 2.5-inch hot-plug SAS/SATA chassis
-
Single-processor configuration
-
UEFI BIOS boot mode
-
TPM 2.0
-
Performance BIOS configuration
Processor
-
1 × Intel Xeon Gold 6526Y
-
16 cores
-
32 threads
-
2.8GHz base clock
-
Turbo Boost supported
-
37.5MB cache
-
195W TDP
-
DDR5-5200 memory support
Memory
-
64GB total DDR5 ECC Registered Memory
-
2 × 32GB DDR5 RDIMM
-
5600MT/s
-
Dual-rank
-
Performance-optimized memory configuration
Storage
-
4 × Dell 1.92TB SATA enterprise SSDs
-
7.68TB total raw SSD capacity
-
2.5-inch hot-plug drive carriers
-
Mixed-use enterprise drives
-
6Gbps SATA
-
512e sector format
-
Rated for 3 drive writes per day
RAID Controller
-
Dell PERC H755 Front RAID Controller
-
Hardware RAID support
-
Drives may be configured into the buyer’s preferred RAID layout
-
No RAID configuration is guaranteed unless otherwise stated
Networking
-
Broadcom 5720 onboard network controller
-
2 × 1Gb Ethernet ports
-
Dedicated iDRAC management port
-
No additional OCP 3.0 network card installed
Remote Management
-
Dell iDRAC9 Enterprise
-
Remote console access
-
Remote power management
-
Hardware monitoring and alerting
-
Virtual media support
Power
-
2 × Dell 800W hot-plug power supplies
-
1+1 redundant power configuration
-
100–240V AC
-
Two North American NEMA 5-15P to C13 power cords included
Expansion
-
Low-profile PCIe riser configuration
-
1 × PCIe Gen4 x16 low-profile slot
Operating System and Licensing
Originally configured by Dell with:
-
Windows Server 2025 Standard
-
16-core factory license
-
Windows Server 2022 Standard downgrade rights
-
Windows Server 2022 downgrade media
-
Windows Server 2025 recovery image
-
Multilanguage support
The Windows Server licensing was factory supplied with this server. Buyer is responsible for confirming activation, licensing suitability, transferability, and compliance for their intended environment.
Included Accessories
-
Dell PowerEdge R660xs server
-
Four installed 1.92TB Dell enterprise SSDs
-
Dell PERC H755 RAID controller
-
Dual 800W power supplies
-
Dell A11 sliding combination rack rails
-
Dell standard front bezel
-
Two power cords
-
Windows Server licensing and media originally supplied with the system
-
Remaining drive-bay blanks and accessories shown in the listing photos
Only the items shown in the photographs or specifically listed above are included.
