The Cisco Meraki C9300-48P-M switch offers 48x 1GB PoE+ RJ-45 ports, along with a single module slot that can accommodate various expansion modules (not included). The available module options include the C9300-NM-4G-M, C9300-NM-8X-M, C9300-NM-2Q-M, C9300-NM—4N/M and theC920-Pro. With a switching capacity of up to 256 Gbps (736 Gbps with stacking), this switch provides high-performance data transfer capabilities. It also boasts a forwarding rate of 190.48 Mpps (547.62 Mpps with stacking) and supports MAC address tables sizes up to 32,000 entries.
- Network Ports : 48x 1 Gigabit Ethernet PoE+ RJ-45
- Product Family : Meraki Catalyst 9300-M Series
- Management Ports : Managed via Cisco Meraki Dashboard
- Stacking Ports : 2x StackWise 480 ports, 2x StackPower connection ports
- Stack Members : Up to eight switches can be connected in the stack | Supported stack members = Other C9300 SKUs with same license level - C9300 higher scale SKUs only stack with other like higher scale models
- Stacking Cable Options : Stackwise - STACK-T1-50CM-M, STACK-T1-1M-M, STACK-T1-3M-M | StackPower - CAB-SPWR-30CM-M, CAB-SPWR-150CM-M
- Module Slots : 1x Expansion Module Slot - Module not Included
- Module Options : C9300-NM-4G-M, C9300-NM-8X-M, C9300-NM-2Q-M, C9300-NM-4M-M, C9300-NM-2Y-M
- AirFlow Direction : Front-to-Back Airflow
- Fan Module Options : 3x FAN-T2-M Field Replaceable Fan Modules Included
- Power Supplies Included : 1x PWR-C1-715WACP-M Power Supply included - 2x Slots
- Power Supply Options : PWR-C1-715WAC-P-M, PWR-C1-350WAC-P-M, PWR-C1-1100WAC-P-M
- PoE Budget : 437W with default PSU - 787W (with 350W Secondary PS), 1152W (with 715W Secondary PS), 1440W (with 1100W Secondary PS)
- Switching Capacity : 256 Gbps (736 Gbps with Stacking)
- Forwarding Rate : 190.48 Mpps (547.62 Mpps with Stacking)
- MAC Address Table Size : 32,000
- Model Number : C9300-48P-M
- Condition : REF
1-YEAR
