Cisco C9500X-28C8D-A Core Switch 28-port 8 uplink 12.8Tbps
Overview
The Cisco Catalyst C9500X-28C8D-A is a high-performance, fixed-core switch designed for enterprise campus core and edge applications. This switch is well-suited for organizations seeking high-performance, scalable solutions for their campus core and edge networking needs
Specification
Ports:
28 × 100 Gigabit Ethernet QSFP28 ports
8 × 400 Gigabit Ethernet QSFP-DD ports
Performance:
Switching Capacity: Up to 12.8 Tbps
Forwarding Rate: 8 billion packets per second (Bpps)
CPU and Memory:
Intel 2.3 GHz x86 CPU with 8 cores
32 GB DDR4 memory
Up to 960 GB SSD for local storage
Dimensions and Weight:
Height: 1.73 inches (4.4 cm)
Width: 17.5 inches (44.5 cm)
Depth: 21.8 inches (55.4 cm)
Weight: Approximately 29.27 lbs (13.28 kg)
Power Supply:
Supports dual redundant, hot-swappable power supplies
Compatible with 1500W AC or DC power supplies
Cooling:
Field-replaceable, hot-swappable fan modules
Option for front-to-back or back-to-front airflow
|
