J9772A- NEW Overview
Aruba 2530 Series Gigabit Ethernet devices are enterprise class, fully managed, Layer 2 edge switches delivering cost effective, reliable, and secure connectivity for business networks. Designed for entry level to midsize enterprise networks, these Gigabit Ethernet switches deliver full Layer 2 capabilities with enhanced access security, traffic prioritization, IPv6 host support, and optional PoE+. The 2530 48G PoE+ model has 48 x 10/100/1000 PoE enabled ports and four Gigabit SFP ports.Quick spec of J9772A- NEW
- Product Code : J9772A
- Type : Aruba 2530-48G-PoE+ Switch
- Ports : · 48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Media Type: Auto-MDIX; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only · 4 fixed Gigabit Ethernet SFP ports · 1 Dual-personality (RJ-45 or USB micro-B) serial console port.
- PoE power : 382 W
- Throughput : Up to 77.3 million pps (64-byte packets)
- Switching capacity : 104 Gb/s
- Dimensions (W x D x H) : 44.3 x 32.26 x 4.45 cm (17.44 x 13.00 x 1.75 in) (1U height)
- Weight : 4.72 kg (10.4 lb)
J9772A- NEW Specification
- Product Model Specification:Value
- Brand:Aruba
- Product Name:J9772A
- Number of Ports:48
- Data Link Protocols:Gigabit Ethernet
- Form Factor:Desktop, Rack-mountable, Wall Mountable
- Layer Supported:2
- Manageable:Yes
- Network Technology:10/100/1000Base-T
- Expansion Slot Type:SFP
- PoE (RJ-45) Port:Yes
- Power Source:Power Supply
- Dimensions (W x D x H):17.44 x 13 x 1.75 inch
- Redundant Power Supply Supported:No
- Product Type:Ethernet Switch
- Warranty:Limited Lifetime Warranty
