Overview
This switch is ideal for high-performance computing (HPC), artificial intelligence (AI), and enterprise data center environments requiring high-speed, low-latency connectivity.
Specifications
- Network Ports: 40 x 200Gb/s HDR QSFP56 ports
- Management Ports: 1 x RJ45 (Management) 1 x RS-232 (Console) 1 x Micro USB
⚙️ Performance and Capacity
- Switching Capacity: Up to 16 Tbps aggregate throughput
- Latency: Sub-130ns port-to-port
- Packet Rate: Up to 7.2 billion packets per second (Bpps)
- Supported Topologies: SlimFly, Dragonfly+, 6D Torus
- Collective Communication: Offloaded via SHARP™ technology
Routing and Management
- Routing: Static and adaptive routing
- Congestion Control: Advanced mechanisms to eliminate fabric congestion
- Management: MLNX-OS® with CLI, WebUI, SNMP, and JSON interfaces On-board subnet manager for up to 2,000 nodes Unified Fabric Manager (UFM®) support
Power and Environmental
- Power Supply: 1+1 redundant, hot-swappable AC PSUs (1100W each)
- Power Consumption: Approximately 274W (ATIS)
- Operating Temperature: 0°C to 40°C
- Non-Operating Temperature: -40°C to 70°C
- Humidity: Operating: 10% to 85% non-condensing
- Altitude: Up to 3,200m
- Noise Level: 71.9 dB(A)
- Form Factor and Compliance
- Form Factor: 1U rack-mountable
- Dimensions: 1.7" (H) x 17" (W) x 23.2" (D)
- Weight: With 1 PSU: 11.4 kg With 2 PSUs: 12.488 kg
- Safety: CB, cTUVus, CE, CU
- EMC (Emissions): CE, FCC, VCCI, ICES, RCM
- RoHS: Compliant
- Included Accessories
- Rack mount kit
- Two (2) AC power cords
- Two (2) AC power supplies
- Six (6) fan modules (Red Fans Rear Exhaust - Front Intake)
1-Year
