NEW Cisco C9200L-48PXG-4X-E 48x 1GB PoE+ RJ45 (12x MultiGB) 4x SFP+ Switch
C9200L-48PXG-4X-E Overview
C9200L-48PXG-4X-E is the C9200L 48-p (12xmGig, 36x1G), 4x10G PoE+, Network Essentials. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.
Quick spec of C9200L-48PXG-4X-E
- Model : C9200L-48PXG-4X-E
- Downlinks total 10/100/1000 or PoE+ copper ports : 48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G)
- Uplink configuration : 4x 10G fixed uplinks
- Default primary AC power supply : PWR-C5-1KWAC
- Fans : Fixed redundant
- Software : Network Essentials
- Stacking bandwidth : 80 Gbps
- DRAM : 2 GB
- Flash : 4 GB
- Switching capacity : 392 Gbps
- Forwarding rate : 291.66 Mpps
- Chassis Dimensions : 1.73 x 17.5 x 13.8 in 4.4 x 44.5 x 35.0 cm
C9200L-48PXG-4X-E Specification
- Downlinks total 10/100/1000 or PoE+ copper ports :48 ports full POE+ (12 mGig ports up to 10G, 36 ports up to 1G)
- Uplink configuration :4x 10G fixed uplinks
- Default primary AC power supply :PWR-C5-1KWAC
- Fans :Fixed redundant
- Software :Network Essentials
- Chassis Dimensions :1.73 x 17.5 x 13.8 in 4.4 x 44.5 x 35.0 cm
- Virtual Networks :1
- Stacking bandwidth :80 Gbps
- Total number of MAC addresses :16,000
- Total number of IPv4 routes (ARP plus learned routes) :11,000 (8,000 direct routes and 3,000 indirect routes)
- IPv4 routing entries :3,000
- IPv6 routing entries :1,500
- Multicast routing scale :1,000
- QoS scale entries :1,000
- ACL scale entries :1,500
- Packet buffer per SKU :6 MB buffers for 24- or 48-port Gigabit Ethernet models
- Flexible NetFlow (FNF) entries :16,000 flows on 24- and 48-port Gigabit Ethernet models
- DRAM :2 GB
- Flash :4 GB
- VLAN IDs :1024
- Total Switched Virtual Interfaces (SVIs) :512
- Jumbo frames :9198 bytes
- Wireless bandwidth per switch :N/A
- Switching capacity :392 Gbps
- Forwarding rate :291.66 Mpps
- Mean time between failures (hours) :337,360
