New Cisco C9200L-24P-4G-E Catalyst 9200L 24x 1GB PoE+ RJ-45 4x 1GB SFP Switch
C9200L-24P-4G-E-Ref Overview
C9200L-24P-4G-E is the Catalyst 9200L 24 ports full PoE+ 4x1G uplink Switch, with Network Essentials software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.
Quick spec of C9200L-24P-4G-E-Ref
- Model : C9200L-24P-4G-E
- Downlinks total 10/100/1000 or PoE+ copper ports : 24 ports full PoE+
- Uplink configuration : 4x 1G fixed uplinks
- Default primary AC power supply : PWR-C5-600WAC
- Fans : Fixed redundant
- Software : Network Essentials
- Stacking bandwidth : 80 Gbps
- DRAM : 2 GB
- Flash : 4 GB
- Switching capacity : 56 Gbps
- Forwarding rate : 83.33 Mpps
- Chassis Dimensions : 1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm
- Weight : 4.35 Kg
C9200L-24P-4G-E-Ref Specification
- Downlinks total 10/100/1000 or PoE+ copper ports :24 ports full PoE+
- Uplink configuration :4x 1G fixed uplinks
- Default primary AC power supply :PWR-C5-600WAC
- Fans :Fixed redundant
- Software :Network Essentials
- Chassis Dimensions :1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm
- Weight :4.35 Kg
- Virtual Networks :1
- Stacking bandwidth :80 Gbps
- Total number of MAC addresses :16,000
- Total number of IPv4 routes (ARP plus learned routes) :11,000 (8,000 direct routes and 3,000 indirect routes)
- IPv4 routing entries :3,000
- IPv6 routing entries :1,500
- Multicast routing scale :1,000
- QoS scale entries :1,000
- ACL scale entries :1,500
- Packet buffer per SKU :6 MB buffers for 24- or 48-port Gigabit Ethernet models
- Flexible NetFlow (FNF) entries :16,000 flows on 24- and 48-port Gigabit Ethernet models
- DRAM :2 GB
- Flash :4 GB
- VLAN IDs :1024
- Total Switched Virtual Interfaces (SVIs) :512
- Jumbo frames :9198 bytes
- Wireless bandwidth per switch :N/A
- Switching capacity :56 Gbps
- Forwarding rate :83.33 Mpps
- Mean time between failures (hours) :392,210
