ASA5506-FTD-K9-New Overview
The ASA5506-FTD-K9 is the ASA 5506-X with Firepower Threat Defense. 8GE. AC.Quick spec of ASA5506-FTD-K9-New
- Product Number : ASA5506-FTD-K9
- Product Description : ASA 5506-X with Firepower Threat Defense. 8GE. AC
- Throughput: Application Control (AVC) : 250 Mbps
- Throughput: Application Control (AVC) and IPS : 125 Mbps
- Stateful inspection throughput (maximum1) : 750 Mbps
- Stateful inspection throughput (multiprotocol2) : 300 Mbps
- Triple Data Encryption Standard/Advanced Encryption Standard (3DES/AES) VPN throughput3 : 100 Mbps
- Users/nodes : Unlimited
- Dimensions(H x W x D) : 1.72 x 7.871 x 9.23 in.(4.369 x 19.992 x 23.444 cm)
- Weight (with AC power supply) : 4 lb (1.82 kg)
ASA5506-FTD-K9-New Specification
- Product Number :ASA5506-FTD-K9
- Product Description :ASA 5506-X with Firepower Threat Defense. 8GE. AC
- Throughput: Application Control (AVC) :250 Mbps
- Throughput: Application Control (AVC) and IPS :125 Mbps
- Maximum concurrent sessions :20,000; 50000
- Maximum New Connections per second :5,000
- Supported applications :More than 3,000
- URL categories :80+
- Number of URLs categorized :More than 280 million
- Centralized configuration, logging, monitoring, and reporting :Multi-device Cisco Security Manager (CSM) and Cisco Firepower Management Center
- On-Device Management :ASDM (version 7.3 or higher required)
- Feature :Cisco ASA 5506-X w/ FirePOWER Services
- Stateful inspection throughput (maximum1) :750 Mbps
- Stateful inspection throughput (multiprotocol2) :300 Mbps
- Triple Data Encryption Standard/Advanced Encryption Standard (3DES/AES) VPN throughput3 :100 Mbps
- Users/nodes :Unlimited
- IPsec site-to-site VPN peers :10; 50
- Cisco AnyConnect Plus/Apex VPN maximum simultaneous connections5 :50
- Virtual interfaces (VLANs) :5; 30
- Security contexts5(included; maximum) :N/A
- High availability :Requires Security Plus License; Active/Standby
- Integrated Wireless Access Point (See Cisco AP 702 datasheet for WiFi technical details) :N/A
- Expansion slot :N/A
- User-accessible Flash slot :No
- USB 2.0 ports :USB port type ‘A’, High Speed 2.0
- Integrated I/O :8 x 1 Gigabit Ethernet (GE)
- Expansion I/O :N/A
- Dedicated management port :Yes (To be shared with FirePOWER Services), 10/100/1000
- Serial ports :1 RJ-45 and Mini USB console
- Solid-state drive :50 GB mSata
- Memory :4 GB
- System flash :8 GB
- System bus :Multibus architecture
- Temperature :32 to 104°F (0 to 40 °C)
- Relative humidity :90 percent noncondensing
- Altitude :Designed and tested for 0 to 10,000 ft (3048 m)
- Acousticnoise :Fanless0 dBA
- Temperature :-13 to 158ºF (-25 to 70ºC)
- Relative humidity :10 to 90 percent noncondensing
- Altitude :Designed and tested for 0 to 15,000 ft (4572 m)
- AC range line voltage :External, 90 to 240 volts alternating current (VAC)
- AC normal line voltage :90 to 240 VAC
- AC current :N/A
- AC frequency :50/60 Hz
- Dual-power supplies :None
- DC domestic line voltage :N/A
- DC international line voltage :N/A
- DC current :N/A
- Steady state :12V @2.5A
- Maximum peak :12V @ 5A
- Maximum heat dissipation :103 British thermal units (Btu)/hr
- Form factor :Desktop, rack mountable
- Dimensions(H x W x D) :1.72 x 7.871 x 9.23 in.(4.369 x 19.992 x 23.444 cm)
- Weight (with AC power supply) :4 lb (1.82 kg)
