Overview
JUNIPER PTX10003-80C-AC ROUTER PTX10003-80C base system with 80 100GE ports or 16 400GE ports, 2 3000W AC power supplies, 2 power cables, and 3 fan trays, with standard tier right-to-use license. The PTX10003-80C-AC is engineered for high-density, high-throughput applications, providing a robust and scalable solution for modern network infrastructures. The Juniper PTX10003-80C-AC is a high-performance, fixed-configuration core router designed for service providers and large enterprises. It offers scalable routing capabilities with a compact 3U form factor, making it suitable for space-constrained environments
Specifications
- Form Factor: 3U rack-mountable chassis
- Dimensions: 17.4 x 5.25 x 31 inches (44.2 x 13.3 x 78.7 cm)
- Weight: Approximately 88 lbs (40 kg)
- Power Supply: Dual redundant 3000W AC power supplies (hot-swappable)
- Cooling: Three hot-swappable fan trays
- Airflow: Front-to-rear (cold aisle to hot aisle) airflow
- ⚙️ Performance and Capacity
- System Throughput: Up to 8 Tbps
- Forwarding Capacity: Up to 5.3 billion packets per second (Bpps)
- Port Density:
- 80 x 100GbE ports
- 16 x 400GbE ports
- Latency:
- 2.5 µs within the Packet Forwarding Engine (PFE)
- 5 µs between PFEs
- Packet Buffer: 64 GB
- System Memory: 64 GB SDRAM
- Storage: Dual 200 GB SSDs in RAID 1 configuration
- Network and Management Ports
- Fixed Ports:
- 8 x 100/400GbE QSFP-DD ports
- 2 x 10/100/1000BASE-T management ports
- 1 x RJ-45 console port
- 1 x USB 3.0 Type-A port
- Network Module Slots: 2 hot-swappable slots supporting various modules, including:
- 8-port 100GbE QSFP28
- 8-port 400GbE QSFP-DD
- 4-port 400GbE QSFP-DD
- 2-port 400GbE QSFP-DD
- Security and Software Features
- Software: Junos OS Evolved
- Security Features:
- Inline AES-256 MACsec encryption on all ports
- Advanced security policies
- Traffic monitoring and anomaly detection
- Routing Protocols:
- IP/MPLS
- Segment Routing (SR)
- BGP, OSPF, IS-IS
- Management and Automation:
- Juniper Networks Junos Space
- Zero-touch provisioning
- REST APIs for automation
- Package Contents
- Juniper PTX10003-80C-AC chassis
- Two 3000W AC power supplies
- Three fan trays
- Rack-mounting hardware
- Power cords (country-specific)
- Documentation
- Deployment Options
- Deployment Scenarios:
- Core routing in service provider networks
- Data center interconnects
- Internet exchange points
- Cloud service provider edge
- High Availability:
- Supports redundant power supplies and fan trays
- Hot-swappable components for minimal downtime
- CONDITION: NEW
- PART # PTX10003-80C-AC
- MODEL: PTX10003-80C base system with 80 100GE ports or 16 400GE ports, 2 3000W AC power supplies, 2 power cables, and 3 fan trays, with standard tier right-to-use license
1-Year
