N3K-C36180YC-R Overview
N3K-C36180YC-R is the Nexus 36180YC-R, with 48p 10/25G and 6p QSFP28. The Cisco Nexus C36180YC-R is a high-speed, high-density, 1, 10, 25, 40, or 100 Gigabit Ethernet switch designed for data center aggregation. The large buffers and routing table sizes of the Cisco Nexus C36180YC-R also make this switch an alternative for a wide range of applications, such as IP storage, Demilitarized Zone (DMZ), big data, and edge routing. The switch comes in a compact 1-Rack-Unit (1RU) form factor and provides extensive Layer 2 and Layer 3 functions. It is part of the R-Series family and runs the industry-leading NX-OS operating system software.Quick spec of N3K-C36180YC-R
- Product Code : N3K-C36180YC-R
- Physical : ·1RU fixed-form-factor switch ·48 SFP ports; each supports native 25, 10, or 1 Gigabit Ethernet mode ·6 QSFP28 ports; each supports native 100 Gigabit Ethernet and 4 x 25 Gigabit Ethernet modes ·2 redundant power supplies ·Management, console, and USB flash-memory ports
- Performance : ·1.8-Tbps switching capacity ·Forwarding rate of up to 1.67 bpps ·Line-rate traffic throughput (both Layer 2 and 3) on all ports, for packet size bigger than 115B ·Configurable Maximum Transmission Unit (MTU) of up to 9216 bytes (jumbo frames)
- Physical dimensions (H x W x D) : 1.72 x 17.3 x 26.85 in. (4.4 x 43.9 x 68.2 cm)
- Weight : 27.1 lb (12.3 kg)
N3K-C36180YC-R Specification
- N3K-C36180YC-R Specification :n/a
- Physical :· 1RU fixed-form-factor switch · 48 SFP ports; each supports native 25, 10, or 1 Gigabit Ethernet mode · 6 QSFP28 ports; each supports native 100 Gigabit Ethernet and 4 x 25 Gigabit Ethernet modes · 2 redundant power supplies · Management, console, and USB flash-memory ports
- Performance :· 1.8-Tbps switching capacity · Forwarding rate of up to 1.67 bpps · Line-rate traffic throughput (both Layer 2 and 3) on all ports, for packet size bigger than 115B · Configurable Maximum Transmission Unit (MTU) of up to 9216 bytes (jumbo frames)
- Hardware tables and scalability :Number of MAC addresses
- Number of VLANS :4096
- Number of spanning-tree instances :· Rapid Spanning Tree Protocol (RSTP): 512 · Multiple Spanning Tree Protocol (MSTP): 64
- Number of ACL entries :· 7000 ingress
- Routing table :· Maximum number of Longest-Prefix-Match (LPM) routes: 256,000 · Maximum number of IP host entries: 750,000 · Maximum number of MAC address entries: 750,000 · Maximum number of Layer 3 multicast entries: 128,000
- Number of EtherChannels :256 (with vPC)
- Number of ports per EtherChannel :32
- Buffer size :8 GB
- System memory :32 GB
- Boot-flash memory :128 GB
- Frequency :50 to 60 Hz
- Power :Power-supply types
- Typical operating power :Watts (W)
- Maximum power :771W
- AC Power-Supply Units (PSUs) · Input voltage · Frequency Efficiency : · 100 to 240 VAC · 50 to 60 Hz 89 to 91% at 220V
- · Power-supply efficiency :· 89 to 91% at 220V
- Maximum heat dissipation :2,631MBTU
- Cooling :Measured sound power (maximum) · Fan speed: 40% duty cycle · Fan speed: 70% duty cycle · Fan speed: 100% duty cycle
- Sound :Dimensions (Height x Width x Depth)
- Environment :Weight
- Temperature: Operating :32 to 104°F (0 to 40°C)
- Temperature: Storage :–40 to 158°F (–40 to 70°C)
- Relative humidity: Operating :· 10 to 85% noncondensing · Up to 5 days at maximum (85%) humidity Recommend American Society of Heating, Refrigeration, and Air-Conditioning Engineers (ASHRAE) data center environment
- Relative humidity: Storage :· 5 to 95% noncondensing
- Altitude :0 to 10,000 ft (0 to 3000m)
