Cisco Meraki CW9164I-MR High-Performance Cloud-Managed 802.11ax Unclaimed WAP REF

Form Factor and Dimensions

• Form Factor: Indoor wall-mounted access point
• Dimensions: 8.9 inches (W) x 8.9 inches (L) x 1.4 inches (H) (226.1 mm x 226.1 mm x 35.5 mm)
• Weight: Approximately 1.5 kg (3.3 lbs)

Wireless Specifications

• Wi-Fi Standard: Wi-Fi 6 (802.11ax) support for faster speeds and improved network efficiency
• Radio Frequency Bands:
• Dual-band: 2.4 GHz and 5 GHz
• 6 GHz: Supported in 6E variants
• MIMO (Multiple Input, Multiple Output): 4x4 MU-MIMO (Multi-User, Multiple-Input, Multiple-Output) for better simultaneous connections and higher throughput
• Max Data Rate:
• Up to 5.4 Gbps total throughput across both bands (2.4 GHz and 5 GHz combined)
• Channel Width: Supports 20, 40, 80, and 160 MHz channel widths for flexible bandwidth configurations
• Antenna: Internal antennas optimized for high-density environments

Connectivity and Ports

• Ethernet Ports:
• 1 x Gigabit Ethernet (1G) port for standard network connectivity
• 1 x 2.5G Ethernet port for higher-speed uplinks and power delivery (PoE+)
• Power over Ethernet (PoE):
• PoE+ (IEEE 802.3at) support for power delivery via Ethernet, eliminating the need for separate power cables

Security and Features

• WPA3, WPA2, and WPA support for enhanced wireless security
• 802.1X for network access control
• Integrated VPN support and intrusion detection/prevention features for secure wireless communications
• Cisco CleanAir: Built-in interference detection and mitigation
• Cisco ClientLink: Optimizes client performance across all devices on the network
• Cisco Band Select: Automatically selects the best band (2.4 GHz or 5 GHz) for client devices

Performance and Capacity

• User Capacity: Supports hundreds of simultaneous users per access point, making it ideal for high-density environments such as large office spaces, educational institutions, and public venues
• Advanced QoS: Quality of Service (QoS) features for traffic prioritization, ensuring high performance for critical applications such as voice and video

Environmental Specifications

• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Non-Operating Temperature: -40°C to 70°C (-40°F to 158°F)
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 95% non-condensing
• Mounting Options: Designed for easy wall-mount installation, perfect for space-constrained areas

• Power and Energy
• Power Supply:
• Powered by PoE+ (Power over Ethernet) for flexibility and ease of installation
• Optional external power adapter for non-PoE environments (sold separately)
• Power Consumption: Approximately 15W (depending on usage and network conditions)

• Software and Management
• Managed via Cisco DNA Center for easy network management and automation
• Supports Cisco Meraki Cloud Management for cloud-based configuration and monitoring
• Cisco Mobility Express: Standalone deployment option for small to medium-sized environments without a controller

• Additional Features
• Mesh Networking: Supports wireless mesh networking for extended coverage without additional cabling
• Cisco Umbrella Integration: Cloud security integration for advanced threat protection and policy enforcement
• Condition : REF
