Overview
The Cisco IE-4010-16S12P is a ruggedized industrial Ethernet switch built for mission-critical networks in harsh environments such as energy, transportation, manufacturing, and outdoor applications. It combines high-density Gigabit Ethernet connectivity with advanced security, resiliency, and simplified management.
This switch provides 28 total Gigabit Ethernet ports, including fiber and copper interfaces, along with Power over Ethernet (PoE/PoE+) support to directly power devices like IP cameras, wireless access points, and sensors. It features a fanless, hardened design with wide operating temperature ranges, ensuring reliable performance in challenging conditions.
Specification
- Total Ports: 28 Gigabit Ethernet
- 12 × 10/100/1000 Mbps copper ports with PoE/PoE+
- 12 × 100/1000 Mbps SFP fiber ports
- 4 × 1 Gbps SFP uplink ports
- Switching Capacity: 56 Gbps non-blocking throughput
- PoE Power:
- Supports PoE/PoE+ (IEEE 802.3af/at)
- Up to 385 W total PoE power budget (with appropriate PSU)
- Form Factor:
- 1 RU, rack-mountable
- Fanless, ruggedized chassis
- Operating Environment:
- Temperature: –40 °C to +75 °C
- Designed for harsh industrial conditions (shock, vibration, and electrical noise resistant)
- Redundancy & Resiliency:
- Ethernet Ring Protection (REP)
- Flex Links and EtherChannel
- Multiple industrial redundancy protocols supported
- Management Options:
- Web GUI (Device Manager)
- CLI (console/SSH)
- SNMP support
- Cisco management platforms integration
- Deployment Features:
- Zero-touch provisioning for faster rollouts
- Field-replaceable SD card for easy replacement/config migration
