Cisco ASR1006 ASR 1006 Router Modular Expansion base w/2 AC

Overview

The Cisco ASR 1006-X Router targets medium and high-end enterprises with up to 100 Gbps total system bandwidth in a 6-rack-unit (6RU) form factor. The Cisco ASR 1006-X is a highly flexible router that is ideal as a WAN aggregation or Internet edge device.

Specifications for the ASR 1006-X

Model: Cisco ASR 1006-X

Form Factor: 6-rack-unit (6RU) form factor

Total System Bandwidth: Up to 100 Gbps

IP Security (IPsec) Throughput: Up to 86 Gbps

Line Card Slots: Two 200 Gbps slots (future-proof for high-density 1, 10, 40, and 100 Gigabit Ethernet ports)

Connectivity Options:

• • • • Shared Port Adapters (SPAs)
      • SPA Interface Processor (SIP)

High Availability:

• • • • Redundant Cisco Route Processor (RP)
      • Embedded Services Processor (ESP)

Power Options: Up to six AC or DC power supplies with N+1 redundancy

Fan Trays: Two field-replaceable fan trays for front-to-back airflow

Datasheet
