Specifications

• Part Number :  CW9163E

• Wireless Standards:
• IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6 and Wi-Fi 6E)
• Frequency Bands:
• 2.4 GHz: 2x2 MIMO
• 5 GHz: 2x2 MIMO
• 6 GHz: 2x2 MIMO
• Maximum Data Rates:
• 2.4 GHz: Up to 574 Mbps
• 5 GHz: Up to 1.2 Gbps
• 6 GHz: Up to 2.4 Gbps
• Aggregate: Up to 3.9 Gbps
• Additional Radios:
• Tri-Band Scanning Radio: 1x1 for dedicated RF monitoring
• IoT Radio: 2.4 GHz for Bluetooth Low Energy (BLE), Zigbee, and Thread
• GNSS Receiver: Built-in for GPS functionality
• Antenna Configuration:
• Four external N-type female connectors supporting various external antennas, including:
  • Omnidirectional Dipole Antenna: CW-ANT-O1-NS-00
  • Directional Patch Antenna: CW-ANT-D1-NS-00
  • Active GPS/GNSS Antenna: CW-ANT-GPS2-00
• Interfaces:
• Ethernet: 1x 100M/1G/2.5G BASE-T (RJ45) with PoE support
• Power Options:
• Power over Ethernet (PoE): 802.3at (PoE+)
• PoE Injectors Supported:
  • AIR-PWRINJ6
  • AIR-PWRINJ7
  • MA-INJ-4
  • MA-INJ-6
  • IW-PWRINJ-60RGDMG
• Environmental Specifications:
• Operating Temperature: -40°C to +65°C (-40°F to +149°F)
• Ingress Protection Rating: IP67
• Wind Resistance: Up to 100 mph sustained and 165 mph gusts
• Physical Dimensions:
• Dimensions: Not specified in the provided sources
• Weight: Not specified in the provided sources
• Security Features:
• Secure Boot
• Trust Anchor module
• Image signing
• Management Options:
• Flexible deployment with support for both on-premises management via Cisco Catalyst 9800 Series Wireless Controllers and cloud-based management through the Meraki dashboard.
